Watec WAT-502B 1/3inch CCD C290K High SNR 570TVL Mini Camera

Ryfutone Co., LTD
Contact Now

Watec WAT-502B 1/3inch CCD C290K High SNR 570TVL Mini Camera

Place of Origin : japan

Brand Name : watec

Model Number : WAT-502B

Delivery Time : 3days

Payment Terms : T/T or PAYPAL

MOQ : 1pcs

Contact Now

Suitable for monitoring, industrial testing equipment

Watec WAT-502B Camera Overview:

The Watec WAT-502B camera is one of the smallest and lightest CCTV box cameras available on the market. This makes it all the more surprising that the manufacturer was able to incorporate into its tiny frame most of the features found on larger and heavier box cameras. The Watec WAT-502B camera have a 1/3" CCD sensor, an auto iris function as well as a full complement of electronic controls. Working in concert, these enable the camera to produce visible images in light levels down to 0.003 lux. This level of low light sensitivity coupled with the camera's incredibly small size make it the camera of choice for residential or commercial applications looking for dependable yet minimally intrusive security monitoring.

Watec WAT-502B Camera Features:

* Ultra compact and lightweight camera suitable for discreet surveillance applications
* Excellent image quality with 1/3" CCD and 400 lines of resolution
* Operates in extremely low light levels (0.003 lux, F1.4)
* Auto iris function ensures properly exposed images in fluctuating light levels
* Back light compensation eliminates silhouetting in situations where the subject matter is brightly lit from behind
* Accepts industry standard CS mount lenses

Specifications:

ModelWAT-502B
CCD1/3"
Effective Pixels290K
Synchronizing Systeminter-sync
Scanning system2:1
video output1Vpp-75Ω
Horizontal resolution400TVL
minimum illumination0.003LuxF1.4(AGCHigh)
automatic gain control5~32dB
SNR50dB
gray propertiesγ≒0.45
Backlight compensation--
Auto electronic shutterFixed electronic shutter OFF(1/50)
Flicker Filter F.L(1/120)
Auto electronic shutter EI(1/50~1/100,000sec)
Auto Iris LensVIDEO
MountCS
Working VoltageDC+9V±10%
working current130mA
Storage Temperature-30℃~+70℃
Operating Temperature-10℃~+40℃
outside dimensions31.5×31×54mm
Weight85g

Watec WAT-502B 1/3inch CCD C290K High SNR 570TVL Mini Camera
