Watec WAT-631S CCD Camera Color Low Illumination Cameras

Name: Watec WAT631S CCD Camera Color Low Illumination Cameras
Brand: watec
Price: 1 USD

Place of Origin : japan

Brand Name : watec

Model Number : WAT-621S

Delivery Time : 3days

Payment Terms : T/T or PAYPAL

MOQ : 1pcs

Contact Now

Watec WAT-631S Camera have 480TVL 0.1 Lx gain and high resolution of the lowest illuminance of gamma correction is optional.
Excellent quality, are suitable for monitoring and image collection.

WATEC WAT-631C Camera Features:

* Watec WAT-631S
* Resolution (horizontal): 480Lines,
* Minimum Illumination (Lux): 0.1Lux F1.2 (AGC High),
* Automatic automatic gain control (dB): ON = 8-36 OFF = 8,
* SNR (dB): 50,
* Gray Features: γ 0.45/1.0,
* Backlight Compensation: ON / OFF,
* Electronic shutter mode: EI 1/50-1/100, 000 sec.FL 1/120 sec. OFF 1/50 sec,
* Automatic iris control: VIDEO / DC .

Watec WAT-631S Specifications:

Model	WAT-631S
image sensor	1/3" CCD
Sensing area(pixel)	P440K
Synchronizing System	Internal Synchronization
Scanning system	2:1
video output	1Vpp-75Ω
Resolution (horizontal)	480Lines
Minimum illumination	0.1Lux F1.2（AGC High）
Gain control	Automatic gain control (dB) ON=8~36 (Hl) 8~24 (LO) OFF=8
S/N ratio	50dB
Gray properties	γ≒0.45/1.0
BLC	ON/OFF
AES EI:OFF	1/50~1/100,000 sec. EI:FL 1/120~1/100,000 sec.
MES	(S)OFF(1/50),1/250,1/500,1/1000,1/2000,1/4000,1/10,000
WB	AUTO/Fixed /3200K，4200K，5100K，6300K
Auto Iris Lens	VIDEO/DC
Mount	CS
Working Voltage	DC+10V~15V
working current (mA)	150
Storage Temperature (℃ )	-30~+70
Operating Temperature (℃ )	-10~+40
Size W×H×L(mm)	35.5×36×64
Weight(G)	90

Watec WAT-631S CCD Camera Color Low Illumination Cameras
